Reloop Beatpad User Manual

ENGLISH
QUICK START GUIDE
MIXER SECTION
1
MASTER Controls the master output volume
2
PHONES Controls your headphone volume
3
CUE MIX Mixes the headphone signal between your
selected channel and the master output signal
4
AUX Controls the output volume to your DJ monitors
5
REC You can record your sets within DJAY by
pressing the REC button
6
CUE Allows you to pre-listen to each deck on your
headphones. SHIFT + CUE activates slip mode.
7
GAIN Fine adjust the input volume for each deck
8
EQ Tweak the high, mid or low frequencies when
mixing your track
9
LINE FADERS Controls your channel volume
10
CROSSFADER Enables you to fade between your decks
1
2
3
4
5
6
9
7
10
8

Reloop Beatpad Specifications

General

Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of mixer channels	2 channels
Number of scratcher platters	2
Built-in display	No
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Docking connector type	Asus 36-pin
Apple docking compatibility	-
Power supply type	AC
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Bundled software	Djay LE Mac Edition DJ

Weight and Dimensions

Depth	325 mm
Width	460 mm
Height	42 mm
Weight	4000 g
