REMA DSD04 Series - Instrument Specifications; Technical Data

32
1.1 TECHNICAL DATA
TECHNICAL DATA - CARATTERISTICHE TECNICHE
CAPACITY (Down Scale)
1,25t
11,5 kN
2.5t
24.5kN
5t
49kN
10t
98.1kN
20t / 25t
196.2/245.3
ACCURACY
NON-REPEATIBILITY
CREEP 30'
TEMPERATURE EFFECT ON ZERO BALANCE
TEMPERATURE EFFECT ON RATED OUTPUT
OPERATING TEMPERATURE RANGE
-10......+55 °C
MAXIMUM SAFE LOAD
200 % F. s.
ULTIMATE LOAD
>500 % F. s.
PROTECTION CLASS
IP 65
MATERIAL : ALUMINIUM
Surface treatment: ANODIZING
 LCD five digits - high 0.67inch
 Power supply - 9V standard battery
 Battery life up to 200 hours
 Choice of unit of measurements: kg - t – ton - lbs - daN - kN
 Tare function
 Peak hold function
 Overload indication on display (110% f.s.)
 Variable response rate by keyboard
POWER SUPPLY
The Dynamometer 04 works with a 9V standard battery which guarantees a life up to 200 hours of regular function, ( with data-
acquisition of 1/sec ), or up to 100 hours in peak-acquisition (cf. 2.2).
A LOW BATTERY message informs the user that the battery runs down. Change the battery as soon as possible although the
instrument can work regularly for about 4 - 8 hours.
For the change of the battery, open the panel at the back of the dynamometer and use only alkaline batteries.
MOUNTING INSTRUCTION OF THE SHACKLES
