ICE MAKER
REMCOR K Model Ice/Beverage dispensers are designed to be used with one of several type top mount ice-
makers. This must be obtained from the appropriate manufacturer.
Check with your REMCOR Sales Coordinator for a list of icemaker kits available. This kit will contain parts and
instructions necessary to connect the icemaker to the ice dispenser.
INSTALLATION INSTRUCTIONS
1. The ice dispenser must be sealed to the counter. The template drawing (See Figure 2) indicates openings
which must be cut in the counter. Locate the desired position for the dispenser, then mark the outline di-
mensions on the counter using the template drawings. Cut openings in the counter.
Apply a continuous bead of NSF International (NSF) listed silastic sealant (Dow 732 or equal) approximate-
ly 1/4 inside of the unit outline dimensions and around all openings. Then position the unit on the counter
within the outline dimensions. All excess sealant must be wiped away immediately. On BC Models, the
sink is shipped loose and is not to be sealed. This is needed for installation of the beverage system and for
service.
2. BC Model beverage connections are made in the front of the unit. With the lower panel removed using
the plumbing schematics (See Figures 6, 7, or 8) or schematic on the rear of the panel to determine syrup
and water connections.
3. Carefully pull the beverage tubes, drain line and power cord through the large opening in the bottom of the
unit.
4. K Models only: Install ice maker according to instructions supplied with kit and manufacturers instructions
supplied with ice maker.
5. Connect the drain tube to an open drain. If additional piping is required, it must be 3/4 IPS (or equal) and
must pitch downward away from the unit for proper drainage.
6. Connect the beverage system product lines as indicated (See Figures 4 or 5). This work should be done by
a qualified service person.
7. Clean the hopper interior (See CLEANING INSTRUCTIONS on pages 11 through NO TAG).
8. Connect the power cord to a 115 volt, 60 cycle, 3-wire grounded receptacle. All electrical wiring must con-
form to national and local electrical codes.
