REMEHA Sol Plus - Page 24

en
24
Installation Indications, functions and options MessagesCommissioningOperation and function
Display channels
Channel Description Connection terminal Page
COL x Temperature collector S1 53
TSTB x Temperature store 1 base S2 53
TSTT x Temperature store 1 top S3 53
S4 x Temperature sensor 4 S4 53
n % x Speed relay R1 54
hP1 x Operating hours R1 R1 55
hP2 x Operating hours R2 R2 55
kWh x* Heat quantity in kWh - 54
MWh x* Heat quantity in MWh - 54
TIME x Time - 55
Adjustment channels
Channel Description Factory setting Page
Arr x System 4 55
PUM1 x Pump control type R1 PSOL 56
nMN x Minimum speed R1 30 % 57
nMX x Maximum speed R1 100 % 57
DT1O x Switch-on temperature difference R1 6.0 K [12.0 °Ra] 56
DT1F x Switch-off temperature difference R1 4.0 K [8.0 °Ra] 56
DT1S x Set temperature difference R1 10.0 K [20.0 °Ra] 56
RIS1 x Rise R1 2 K [4 °Ra] 56
S1MX x Maximum store temperature 1 75 °C [167 °F] 56
DT2O x Switch-on temperature difference R2 6.0 K [12.0 °Ra] 56
DT2F x Switch-off temperature difference R2 4.0 K [8.0 °Ra] 56
DT2S x Set temperature difference R2 10.0 K [20.0 °Ra] 56
RIS2 x Rise R2 2 K [4 °Ra] 56
S2MX x Maximum store temperature 2 75 °C [167 °F] 56
EM x Collector emergency temperature 130 °C [270 °F] 56
OCC x Collector cooling option OFF 58
CMX x* Maximum collector temperature 110 °C [230 °F] 58
OSYC x System cooling option OFF 59
DTCO x* Switch-on temperature difference cooling 20.0 K [40.0 °Ra] 59
DTCF x* Switch-off temperature difference cooling 15.0 K [30.0 °Ra] 59
