19
Spare parts list
No.
Description EDP no.
1 Transport handle 1101142
2 Exterior cladding 1101420
2a Exterior cladding (stainless steel) 1101461
3 Insulation 1101421
4 Combustion chamber 1101422
5 Gas burner 1101423
6 Protective outlet grille 1101424
7 Gas nozzle 1101426
8 Gas supply pipe R/D 1101457
9 OT elbow union 1101316
10 Ignition electrode 1101280
11 Ionisation electrode 1101186
12 Ionisation cable 1101187
13 Connection clip 1101181
14 Ignition cable 1101521
15 Support, front 1101427
16 Unit base 1101428
17 Inspection cover 1101469
19 Gas supply pipe M/R 1101441
20 Screw connection M10x1 1101409
21 Terminal block 4x 1101442
22 Gas control 1101412
23 Support, rear 1101249
24 GE-screw connection 1101396
25 Automatic burner base 1102534
26 Automatic burner 1101526
27 Push-button extension 1101524
28 Cover 1101525
29 Nozzle 1101528
No.
Description EDP no.
30 Safety thermostat 1101197
31 Solenoid valve 1101376
32 Thermostat socket 1101018
33 Strapping plug 1101019
34 Gas connection nipple 1101134
35 Adjusting knob, cpl. 1101192
36 Strain relief 1101267
37 Operating switch 1101188
38 Cyclical igniter 1101520
39 Grommet 1101304
40 Mains cable with plug 1101320
41 Protective intake grille 1101432
42 Fan motor 1101254
43 Drive clutch B 8 Ø 1101255
44 Fan blade 1101150
45 Retaining clip 1101395
46 Clutch plate 1101375
xx Run-on relay (accessory) 1105075
xx
Pressure controller with hose breakage protection
1101470
xx 2 linear m. Gas hose 1101419
xx 2 linear m. HP gas hose
1)
1101174
xx 5 linear m. HP gas hose
1)
1108410
xx 10 linear m. HP gas hose
1)
1108411
xx Multi-cylinder set (2-3 cylinders), cpl. 1014050
xx T-connection for multi-cylinder set 1101177
xx Nylon seal for T-connection 1101178
xx HP hose 0.4 m
2)
1101179
xx Thermostat plug 1101020
When ordering spare parts, please state the EDP no., unit number and type (see name plate)!
xx = not illustrated
1)
Version for construction site operation per DIN 4815 part 1, pressure class 30
2)
for multi-cylinder set
