21
Spare parts list
No. Designation EDP no.
1 Transport handle 1101680
2 Exterior cladding 1101681
2a Exterior cladding (stainless steel) 1101462
3 Insulation 1101682
4 Grommet 1101304
5 Retaining clip 1101395
6 Aftercooler thermostat 1101683
7 Protective outlet grille 1101684
8 Safety thermostat 1101197
9 Combustion chamber 1101685
10 Interior cladding, front 1101686
11a Cladding support, right 1101631
11b Cladding support, left 1101632
12 Mounting plate 1101687
13 Unit base 1101688
14 Floor panel 1101652
15 Axle 1101653
16 Wheel 1102155
17 Locking ring 1101622
18 Hubcap 1101623
19 Push-button extension 1101524
20 Cover 1101525
21 Nozzle 1101528
22 Gas supply pipe M/R 1101441
23 GE-screw connection 1101396
24 Solenoid valve 1101165
25 Automatic burner base 1102534
26 Automatic burner 1101526
27 Inspection cover 1101651
28 Screw connection M10 x 1 1101409
29 Gas supply pipe R/D 1101690
30 Support, rear 1101691
31 Operating switch 1101188
32 Strain relief 1101267
33 Mains cable with plug 1101320
34 Strapping plug 1101019
No. Designation EDP no.
35 Thermostat socket 1101018
36 Adjusting knob, cpl. 1101192
37 Gas connection nipple 1101134
38 Fastening bracket 1102906
39 Gas control 1101692
40 Terminal block 6er 1101366
41 Auxiliary relay 1108038
42 Ignition transformer 1101666
43 Grommet, large 1101677
44 Protective intake grille 1101648
45 Fan blade 1101693
46 Fan housing, cpl. 1101694
47 Fan motor 1101634
49 Gas burner 1101695
50 Gas nozzle 1101659
51 OT elbow union 1101316
52 Ignition cable 1101696
53 Connection clip 1101181
54 Ionisation cable 1101187
55 Ignition electrode 1101698
56 Ionisation electrode 1101697
57 Electrode bracket 1101633
58 Interior cladding, rear 1101450
59 Spacer sleeve 1101699
Without figure:
Pressure controller 1101418
Hose breakage protection 1101664
2 linear m. Gas hose 1101419
2 linear m. HP gas hose
1)
1101174
5 linear m. HP gas hose
1)
1108410
10 linear m. HP gas hose
1)
1108411
Multi-cylinder set (2-3 cylinders), cpl. 1014050
T-connection for multi-cylinder set 1101177
Nylon seal for T-connection 1101178
HP hose 0.4m for multi-cylinder set 1101179
Thermostat plug 1101020
When ordering spare parts, please state the EDP no., unit number and type (see name plate)!
1)
Version for construction site operation per DIN 4815 part 1, pressure class 30
