Technical data
1)
Noise measurement in acc. with DIN 45635 - 01 - KL 3 in heating mode
Series PGT 30 (E) PGT 60 (E) PGT 100 (E)
Max. nominal heating capacity kW 26 55 100
Heating capacity, adjustable kW 10 to 26 25 to 55 50 to 100
Air volume m
3
/h 800 1450 3600
Fuel / gas type Liquid gas cat I
3B/P
Unit connection pressure bar 1.5 1.5 1.5
Unit connection value kg/h 0.78 - 2.0 1.95 - 4.27 3.9 - 7.8
Power supply V/Hz 230/1~/50 230/1~/50 230/1~/50
Max. power consumption W 70 110 325
Elec. Max. current consumption
A 0.5 0.95 2.8
Electrical protection (provided by the customer)
A 10 10 10
Enclosure class IP 44 44 44
Sound pressure level L
pA
1m
1)
dB (A) 56 - 69 62 - 72 74 - 82
Dimensions: Length mm 450 650 1060
Width mm 260 320 435
Height mm 410 510 620
Weight (without accessories) kg 12 20 47
Product ID number CE-0085AP0240
Technical data for the automatic burner
Operating voltage 230 V (-15 % + 10 %)
Frequency 50 Hz (40 - 60 Hz)
Safety time 5 seconds
Waiting time after fault shut-down approx. 60 seconds
Permissible ambient temperature – 20° C to + 60 °C
min. required ionisation flow 5 μA
Sensitivity (ionisation flow) 1 μA
Enclosure class IP 44
We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
