14.2 Spare parts list
No. Designation RBW 301 PV RBW 301 PV-S
From serial number: 1740N... 1741N...
1 Casing, front 1110769 1110769
2 Casing, top (cover) 1110775 1110775
3 Complete operating unit including circuit board 1110800 1110800
4 Solenoid valve 1110740 1110740
5 High pressure switch 1110771 1110771
6 Compressor 1110774 1110774
7 Electronic expansion valve 1110772 1110772
8 Heat exchanger (evaporator) 1110770 1110770
9 Fan blade 1110747 1110747
10 Compressor capacitor 15 nF 1110802 1110802
11 Fan motor 1110749 1110749
13 Safety temperature limiter (STB) 1110760 1110760
14 Electrical heating coil, 1.5 kW 1110766 1110766
15 Ventilation elbow half shell (left) 1124195 1124195
16 Ventilation elbow half shell (right) 1124196 1124196
16.1 Half shell ventilation grille 1124197 1124197
When ordering spare parts, please always state the EDP number, unit number and unit type (see name
plate)!
59
