2 Technical data
2.1 Unit data
Series RKL 495 DC
RKL 495 DC
Operating mode Local inverter room air conditioner in split design
Nominal cooling output
1)
kW 4.30
Energy efficiency ratio
1)
B
Energy efficiency ratio SEER
1)
4.74
Power consumption, annual, Q
CE
kWh 318
Application area (room volume), approx.
m
3
120
Adjustment range indoor unit °C/%r.H. +16 to +30 / 35 to 80
Operating range outdoor unit °C/%r.H. +21 to +43 / 35 to 80
Refrigerant
R32
3)
Refrigerant, basic quantity kg 0.97
CO
2
equivalent t 0.66
Max. operating pressure kPa 4200
Air volume flow per level, indoor unit
m
3
/h
350/450/550
Max. airflow volume outdoor unit
m
3
/h
930
Sound press. level p. stage, ind. unit
2)
dB(A) 47/50/54
Sound power level max., IT/AT dB(A) 57.0/62.0
Power supply V/Hz 230/1~/50
Enclosure class indoor unit / outdoor unit IP 24/X4
Electr. rated power consumption
1)
kW 1.37
Electr. rated current consumption
1)
A 5.82
Elec. starting current max., LRA A 8.00
Condensate pump, flow rate, max. mm WS 1800
Refrigerant piping, length mm 3000, 2300 usable
Dimensions indoor unit H/W/D mm 695/470/335
Dimensions outdoor unit H/W/D mm 490/510/230
Weight indoor unit kg 38.0
Weight outdoor unit kg 12.0
Standard colour white silver
Serial number 1926... 1927...
EDP no. 1616495 1616496
1)
Air inlet temperature TK 27 °C / FK 19 °C, outdoor temp. TK 35 °C, FK 24 °C, max. air flow
2)
Gap 1 m free space /
3)
Contains greenhouse gas according to Kyoto protocol, GWP 675
