2.7 Electrical connection
general notes
n It is necessary to lay a mains cable both to the
outdoor unit and, separately
, to the indoor unit.
n Power to the indoor units may not be discon-
nected by the power company when fitted with
an off-period circuit (anti-freeze protection).
n All indoor units require a single-phase
230V/1~/50 Hz power supply.
The outdoor units of the WKF/WKF compact
80 to 130 series require a single-phase power
supply of 230V/1~/50 Hz and the outdoor units
of the WKF/WKF compact 170 series require a
three-phase power supply of 400V/3~/50 Hz.
n The electrical connection between outdoor and
indoor units is made using a sheathed two-wire
control line.
n Where applicable, another three-phase
400V/3~/50 Hz power supply shall be provided
to the indoor module for auxiliary heater.
n The Smart-Control needs to know from the
power-company whether the power supply is
enabled or a blocking period is in effect. A
potential-free switch must be provided by the
customer for this purpose and connected to
contact S16. (Contact closed signifies enabled,
while contact open signifies a blocking period).
n A connection schematic along with corre-
sponding circuit diagrams can be found in the
“Electrical layout” and “Circuit plans” chapters
of this manual.
n Special rates for the operation of heat pumps
may be offered by the power utility.
n Ask your local power utility about the details of
any rates that might be available.
DANGER!
All electrical installation work must be done by
an electrician.
WARNING!
Always note the currently applicable VDE
guidelines and the notes in T
AB 2007. The size
and type of the fuse are to be taken from the
technical data.
WARNING!
All cable sizes are to be selected according to
VDE 0100. Special attention should be given to
cable lengths, cable type and the kind of instal-
lation. The information in the connection dia-
gram and in the system overview are to be
seen as an acceptable installation possibility
only in a standard case!
NOTICE!
Make sure to connect the outdoor unit neutral
connector properly, otherwise the varistors on
the line-filter circuit board will be destroyed.
NOTICE!
The electrical connection for the units must be
made at a separate feedpoint with a residual
current device in accordance with local regula-
tions and should be laid out by an electrician.
Check all plugged and clamped terminals to
verify that they are seated correctly and make
permanent contact. T
ighten as required.
2.8 Electrical connection - indoor
unit
The following instructions describe the electrical
connection of the WKF/WKF compact and WKF
Duo series.
1. Remove the housing from the upper section
by pressing it upwards and pulling it forwards
out of the rear groove.
2. Guide the supply cable to the indoor units
through the cable openings, and also route
the control line between indoor and outdoor
units and the cables for external devices and
probes into the indoor unit. Note that the
cable openings in the WKF/WKF compact
series are located above rather than below.
3. Connect the power supply of the indoor units
to the terminals.
4. Connect all secondary consumers
(HGM,HGU, changeover valves etc.) to the
I/O module.
