3.6 Terminal assignment / legend - I/O module 01 - WKF 130/170 Duo
Designation Input Output Signal Description
Power X Power supply I/O 230V
PP X Power supply primary pump, indoor unit
S01.1 X Solar probe collector
S02.1 X Solar probe storage tank, bottom
S03.1 X Solar probe inlet HM solar
S04.1 X Solar probe RF HM solar
S05.1 X Circulation RF temp./impulse
S06.1 X 2nd mixed heating cycle inlet probe
S07.1 X Probe refrigerant piping
S08.1 X Domestic hot-water tank
S09.1 X
Probe storage tank centre
(storage energy acquisition)
S10.1 X External probe
S11.1 X 1st mixed heating cycle RF probe
S12.1 X 1st mixed heating cycle inlet probe
S13.1 X Heat pump inlet
S14.1 X 2nd mixed heating cycle RF probe
S15.1 X Heat pump RF
S16.1 X Energy supplier contact (NC) / dew point monitoring
S20.1 X Not connected
S21.1 X Not connected
S22.1 X Not connected
S23.1 X Ultrasonic flow rate meter Solar, pulse rate
S24.1 X Ultrasonic flow rate meter HP, impulse rate
S25.1 X HP electricity meter S0
S26.1 X Household electricity S0
S27.1 X Flow probe
S28.1 X PV yield electricity meter S0
S29.1 X PV in-feed electricity meter S0
A01.1 X Solar pump unregulated (230V)
A02.1 X 1st mixed heating cycle pump (230V) switched
A03.1 X Unmixed heating cycle pump (230V)
A04.1 X Circulation pump (230V)
A10.1 X Changeover valve, hot water preparation
A11.1 X Changeover valve 2nd WE Smart BVT
REMKO WKF series
34
