8 Configuration
The units can also be adjusted to requirements ret-
roactively by adjusting DIP switch blocks SW1 to
SW3 accordingly
.
The DIP switch block SW1 configures the network
addresses within a bus.
The DIP switch block SW2 configures the config-
ured unit-specific parameters and must be set in
accordance with the table below.
The DIP switch block SW3 configures the function
of the unit.
The configuration takes place by setting the white
slide switch.
Network configuration (SW1)
The addresses for the leading (master) and subse-
quent (slave) units are defined using switch block
SW1.
SW1
Network S1 S2 S3 S4 S5 S6
Master OFF OFF OFF OFF OFF ON
Slave 1 OFF OFF OFF OFF OFF OFF
Slave 2 ON OFF OFF OFF OFF OFF
Slave 3 OFF ON OFF OFF OFF OFF
Slave 4 ON ON OFF OFF OFF OFF
Slave 5 OFF OFF ON OFF OFF OFF
Slave 6 ON OFF ON OFF OFF OFF
Slave 7 OFF ON ON OFF OFF OFF
Slave 8 ON ON ON OFF OFF OFF
Slave 9 OFF OFF OFF ON OFF OFF
Slave 10 ON OFF OFF ON OFF OFF
Slave 11 OFF ON OFF ON OFF OFF
Slave 12 ON ON OFF ON OFF OFF
Slave 13 OFF OFF ON ON OFF OFF
Slave 14 ON OFF ON ON OFF OFF
Slave 15 OFF ON ON ON OFF OFF
Slave 16 ON ON ON ON OFF OFF
Slave 17 OFF OFF OFF OFF ON OFF
Slave 18 ON OFF OFF OFF ON OFF
Slave 19 OFF ON OFF OFF ON OFF
Slave 20 ON ON OFF OFF ON OFF
Slave 21 OFF OFF ON OFF ON OFF
Slave 22 ON OFF ON OFF ON OFF
Slave 23 OFF ON ON OFF ON OFF
Slave 24 ON ON ON OFF ON OFF
Slave 25 OFF OFF OFF ON ON OFF
Slave 26 ON OFF OFF ON ON OFF
Slave 27 OFF ON OFF ON ON OFF
Slave 28 ON ON OFF ON ON OFF
Slave 29 OFF OFF ON ON ON OFF
Slave 30 ON OFF ON ON ON OFF
Slave 31 OFF ON ON ON ON OFF
Slave 32 ON ON ON ON ON OFF
41
