15.4 Spare parts list WLT 80 EC - WLT 90 EC
IMPOR
TANT!
To ensure the correct delivery of spare parts, please always the device type with the corresponding serial
number (see type plate)
No. Designation
1 Unit trim
2 Air filter, left or right
3 Air filter, centre
4 Housing front, complete
5 Air inlet grill
6 Unit housing, front
7 Condensate tray, complete
8 Condensate tray
9 Swing motor
10 Air outlet flap, vertical right
11 Air outlet flap, vertical left
12 Air outlet flap, horizontal narrow
13 Air outlet flap, horizontal wide
14 Condensate hose
15 Finned heat exchanger
16 Aerator roller, left
17 Aerator roller, right
18 Fan motor, left
19 Fan motor, right
20 Housing corner, right
21 Housing corner, left
22 Unit housing, rear
23 Fan motor fastening, right
24 Fan motor fastening, left
25 Wall bracket
26 Bracket, complete
27 Bracket, filter components
28 Bracket, receiver display
29 Bracket, board
30 Infrared remote control
