Overload Fault
Over Load in EPS Mode.
• Turn off high power device , press “ESC” to restart the
inverter.
• Or seek help from us, if cannot go back to normal state.
EPS OCP Fault
Over Current in EPS Mode.
• Make sure the load power is within the EPS power range.
• Check if any nonlinear load is connect on the EPS. Remove
this load
to check if can recover.
• Or seek help from us, if cannot go back to normal state.
DCI Device Fault
DCI Device Fault
• Disconnect solar power PV+ , PV- and battery, reconnect
them.
• Or seek help from us, if cannot go back to normal state.
AC HCT Fault
AC Current Sensor Fault
• Disconnect solar power PV+ , PV- and battery, reconnect
them.
• Or seek help from us, if cannot go back to normal state.
EPS Relay Fault
EPS Relay Fault
• Disconnect solar power PV+ , PV- , grid and battery,
reconnect them.
• Or seek help from us, if cannot go back to normal state.
TZ Protect Fault
Over current Fault.
• Wait for a while to check if go back to normal status.
• Disconnect solar power PV+ , PV- and battery, reconnect
them.
• Or seek help from us, if cannot go back to normal state.
Grid Lost Fault
Grid is Lost.
• System will reconnect if the utility is back to normal.
• Or seek help from us.
Grid Volt Fault
Grid Voltage Out of Range
• System will reconnect if the utility is back to normal.
• Or seek help from us.
Grid Freq Fault
Grid Frequency out of range
• System will reconnect if the utility is back to normal.
• Or seek help from us.
PLL Lost Fault
The Grid is Not Good.
• System will reconnect if the utility is back to normal.
• Or seek help from us.
Bus Volt Fault
Bus Voltage out of Normal Range.
• Disconnect solar power PV+ , PV- and battery, reconnect
them.
• Check if the PV input is within the range of the inverter.
• Or seek help from us, if cannot go back to normal state.
In OCP Fault
Inverter over current protection fault
• Wait for a while to check if back to normal.
• Or seek for help from us.
PV Volt Fault
PV Voltage Fault
• Check the output of the PV voltage.
• Or seek for help from us.
AC10M Volt Fault
The grid's Voltage is out of range for the last 10 minutes.
• The system will back to normal if the grid is back
• Or seek for help from us.
Isolation Fault
Isolation Fault
• Check the connection of the inverter.
• Or seek for help from us.
