FUSES
6
Num-
ber
Allocation
A
Accessories relay
B
Reverse light relay
1
Second row Accessory
socket
2
Left-hand main beam
headlight
3
Right-hand main beam
headlight
4
Left-hand dipped beam
headlight
5
Right-hand dipped beam
headlight
6
Left-hand side light
7
Cluster /Radio/ Ultra low
cost/
8
First Row Accessory
Socket
9
Blower Motor
10
Fuel Pump Fuse
Num-
ber
Allocation
11
Starter - Manual
Transmission / Automated
Manual transmission
12
Roof Light
13
Cluster
14
Low Beam
15
Radio/Ultra low cost/Diag-
nostic Socket, Roof Light/
Multimedia accessory
socket
16
Empty location
17
Cluster
18
Lighting Switch
19
Electrical Door Locking
20
Electrical Door Locking
21 to
23
Empty location
24
Cluster,Fuel pump,Control
Unit-Engine/
Powertrain,Starter
Number Allocation
25
Stop Light Switch, Radio/
Ultra Low cost
26
Rear Light Switch
27
Windshield Motor
28
Front Dual Window Lift
29
Power Steering
30
Air-Bag
31
Empty location
32
ABS/Stoplight/
Transponder
33
Reverse parking
34
Day light running lamp
35
Rear power window
36
Outside rear view mirror
37 to 39
Empty location
|
140 - Practical advice
