REVERSING CAMERA
3
Static guide line
3
:
The static guide line
3
has coloured
markers
A
,
B
and
C
showing the dis-
tance behind the vehicle:
–
A
(red) approximately 30 centime-
tres from the vehicle;
–
B
(yellow) approximately 70 cen-
timetres from the vehicle;
–
C
(green) approximately 150 cen-
timetres from the vehicle.
The screen shows a re-
verse image.
The frames are a repre-
sentation projected onto flat
ground; this information must
not be taken into account when
superimposed on a vertical ob-
ject or an object on the ground.
Objects which appear on the
edge of the screen may be de-
formed.
In very bright light (snow, vehi-
cle in sunshine etc.), the camera
vision may be adversely affect-
ed.
This gauge remains fixed and indi-
cates the vehicle trajectory if the
wheels are in line with the vehicle.
Driving - 81
|
