4.6
ENG_UD1390_1
Niveau huile moteur (X44 - Renault)ENG_NU_773-1_X44_Renault_4
ENGINE OIL LEVEL (continued)
Topping up/filling
The vehicle must be parked on level
ground and the engine should be cold
(for instance, before the engine is
started up for the first time in the day).
Engine oil grade
Refer to the Maintenance Service
Booklet for your vehicle for information
regarding which grade of oil to use.
– Unscrew cap
1;
– top up the level (as a guide, the ca-
pacity between the minimum and
maximum reading on dipstick
2 is
between 1.5 and 2 litres, depending
on the engine);
– wait for approximately 10 minutes to
allow the oil to flow into the engine;
– check the level using dipstick
2 (as
described above).
Do not exceed the
maximum level and
do not forget to refit cap 1.
When working in the engine
compartment, ensure that
the windscreen wiper stalk
is in the park position.
Risk of injury.
1
1
2
2
1
2
