E2 Lite Setup
R20UT3240EJ0300 Rev.3.00 Page 22 of 36
May.15.20
CAUTION
Notes on connector insertion and removal:
When connecting or disconnecting the user-system interface cable and the emulator or user system,
grasp the connector at the end of the cable. Pulling the cable itself will damage the wiring.
Also, be aware that the user-system interface cable has the direction in which it must be inserted. If
the cable is connected in the wrong direction, it may be damaged.
Correct example Incorrect example
