Location
Circuit Group
Default Open/Closed
Function
E13
MCU Clock
Open
Connects P212/EXTAL pin to pin headers
E8
Ethernet
Closed
Connects P706 (IRQ7) to Ethernet IRQ
E9
Ethernet
Closed
Connects P401 to Ethernet MDC
E10
Ethernet
Closed
Connects P402 to Ethernet MDIO
E14
Ethernet
Closed
Connects P406 to Ethernet TXD1
E15
Ethernet
Closed
Connects P700 to Ethernet TXD0
E16
Ethernet
Closed
Connects P405 to Ethernet TXD_EN
E17
Ethernet
Closed
Connects P703 to Ethernet RXD1
E18
Ethernet
Closed
Connects P702 to Ethernet RXD0
E19
Ethernet
Closed
Connects P705 to Ethernet CRS_DV
E20
Ethernet
Closed
Connects P704 to Ethernet RX_ER
E21
Ethernet
Closed
Connects P701 to Ethernet REF50CK0
E22
Ethernet
Closed
Connects P403 to Ethernet RST#
E23
Pmod1
Open
Connects P415 (SCL2) to Pmod1
E24
Pmod1
Open
Connects P414 (SDA2) to Pmod1
E25
Pmod1
Open
Connects +5.0 V to Pmod1
E36
Pmod1
Closed
Connects P301 (SSLA2) to Pmod1
E37
Pmod1
Closed
Connects P302 (SSLA3) to Pmod1
E38
Pmod1
Closed
Connects +3.3 V to Pmod1
E26
User LED
Closed
Connects P007 to User LED2
E27
User LED
Closed
Connects P006 to User LED1
E28
User LED
Closed
Connects P008 to User LED3
E29
Debug MCU
Power
Closed
Connects the Debug MCU power to +3.3 V
E30
JTAG
Closed
Connects the JTAG GND Detect pin on J20 and
J13 to GND
E31
User Switch
Closed
Connects P005 to User Switch S1
E32
User Switch
Closed
Connects P004 to User Switch S2
E33
CAN
Open
Connects P611 to CAN Standby
E34
CAN
Open
Connects P610 to CAN RXD
E35
CAN
Open
Connects P609 to CAN TXD
E39
Pmod2
Open
Connects P512 (SCL1) to Pmod2
E40
Pmod2
Open
Connects P511 (SDA1) to Pmod2
E41
Pmod2
Open
Connects +5.0 V to Pmod2
E42
Pmod2
Closed
Connects P708 (SSLB3) to Pmod2
E43
Pmod2
Closed
Connects P408 (GPIO) to Pmod2
E44
Pmod2
Closed
Connects +3.3 V to Pmod2
