Renesas RH850/D1x - Test Pin Connectors

D1M2H Mango Adapter Board Manual
【CONFIDENTIAL】
23
Pin
Function / Port
Pin
Function / Port
119
P10_0
120
P44_4
121
P10_1
122
P44_3
123
P10_2
124
P44_2
125
P10_3
126
P44_1
127
P10_4
128
P44_0
129
P10_5
130
131
P10_6
132
P11_0
133
P10_7
134
P11_1
135
P10_8
136
P11_2
137
P10_9
138
P11_3
139
P10_10
140
P11_4
141
P10_11
142
P11_5
143
144
P11_6
145
ETNB0MDIO
146
P11_7
147
ETNB0MDC
148
149
P467_ETNB0TXD3
150
P42_ETNB0TXD3
151
P467_ETNB0TXD2
152
P42_ETNB0TXD2
153
P467_ETNB0TXD1
154
P42_ETNB0TXD1
155
P467_ETNB0TXD0
156
P42_ETNB0TXD0
157
P467_ETNB0TXEN
158
P42_ETNB0TXEN
159
P467_ETNB0TXER
160
P42_ETNB0TXER
161
P467_ETNB0COL
162
P42_ETNB0COL
163
P467_ETNB0RSDV
164
P42_ETNB0RSDV
165
P467_ETNB0TXCLK
166
P42_ETNB0TXCLK
167
P467_ETNB0RXCLK
168
P42_ETNB0RXCLK
169
P467_ETNB0RXD3
170
P42_ETNB0RXD3
171
P467_ETNB0RXD2
172
P42_ETNB0RXD2
173
P467_ETNB0RXD1
174
P42_ETNB0RXD1
175
P467_ETNB0RXD0
176
P42_ETNB0RXD0
177
P467_ETNB0RXDV
178
P42_ETNB0RXDV
179
P467_ETNB0RXER
180
P42_ETNB0RXER
181
GND
182
GND
183
GND
8.2 Test pin connectors
Note: The test-pin headers CN3 to CN12 are directly connected to the MCU pins,
therefore special care must be taken to avoid any electrostatic or other damage
to the device.
Table 8-3: Pin assignment of connector (CN3) P0
Pin
Power Domain
Port
Pin
Power Domain
Port
1
EVCC
P0_0
2
EVCC
P0_1
3
EVCC
P0_2
4
EVCC
P0_3
5
EVCC
P0_4
6
EVCC
P0_5
7
EVCC
P0_6
8
EVCC
P0_7
9
EVCC
P0_8
10
EVCC
P0_9
Table 8-4: Pin assignment of connector (CN4) P10
Pin
Power Domain
Port
Pin
Power Domain
Port
1
A0VCC
P10_0
2
A0VCC
P10_1
3
A0VCC
P10_2
4
A0VCC
P10_3
5
A0VCC
P10_4
6
A0VCC
P10_5
7
A0VCC
P10_6
8
A0VCC
P10_7
9
A0VCC
P10_8
10
A0VCC
P10_9
11
A0VCC
P10_10
12
A0VCC
P10_11
