Renesas RH850/D1x User Manual

D1M2H Mango Adapter Board Manual
【CONFIDENTIAL】
6
1 Introduction
The RH850/D1x Application Board is part of the RH850 Evaluation Platform and serves as a simple and
easy to use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/D1x
microcontrollers.
Since the adapter board can not be used as a standalone board, this board has to be mated with a
mainboard for full functionality.
Main features of the adapter board:
 Socket for mounting a device
 Power supply from main board
 Device programming capability (Connector on main board)
 Device debugging capability (Connector on main board)
 Pin headers for direct access to each device pin
 MainOSC and SubOSC circuitry
 Connectors to MainBoard
 SDRAM and Serial Flash Memory
This document describes the functionality provided by the adapter board and guides the user through its
operation.
For details regarding the operation of the microcontroller, refer to the RH850/D1x User Manual.
