RSKRX111 6. Reviewing the Tutorial Program
R20UT2194EG0100 Rev. 1.00 Page 22 of 27
Jul 3, 2013
• Press [F5] to resume program
execution.
• Observe the string on the bottom line
of the LCD change one character at
a time from ‘STATIC’ to ‘TESTTEST’
as the ‘static_test’ function is
executed.
•
After all characters have been
changed, the LCD panel’s second
line will return to displaying ‘
RX111’.
• Press the ‘Stop’ button to halt
program execution.
• This is the extent of the tutorial code.
For further details regarding hardware configuration, please refer to the RX Family Software Manual and the RX111
Hardware Manual.
The E1 emulator features advanced logic-based event point trigger system, and full instruction on its use is outside the
scope of this tutorial. For further details, please refer to the E1 Emulator User’s Manual
