M4 (× 2)
Standard DIN rail mounting
Alternative mounting
79.75
(3.14)
NOTE: Lift spring end plate to attach OSI to DIN rail.
OSI/OSI-D with OMM-2C installation guide
3.4
System installation
Mounting the OSI/OSI-D to a DIN
rail
Dimensions mm (in)
