Product Description
PH10T PLUS A shank-mounted head with two-wired probe capability and an M8
thread.
PH10M PLUS A shank-mounted head with multiwired probe capability and a
Renishaw autojoint.
PH10MQ PLUS A quill-mounted head with multiwired probe capability and a
Renishaw autojoint.
HCU2 A hand control unit for use with PH10 measurement systems.
PHC10-3 PLUS A controller for use with PH10 measurement systems.
The PH10 PLUS range of motorised heads consists of three different models:
Each head in the PH10 PLUS range is a general purpose, versatile unit designed specifically for use on direct computer controlled (DCC)
CMMs and incorporates the following features:
720 indexing positions
0.4 μm indexing repeatability
7.5° indexing steps in both axes
300 mm (maximum) extension bar capability *
* NOTE: 450 mm is possible for PH10M PLUS / PH10MQ PLUS with special order carbon fibre extensions.
WARNING: The components of the PH10 PLUS system are not compatible with PH9 system components. No attempt should be
made to connect PH10 PLUS system components to a PH9 system, as this will result in damage to the product.
