Adjustment modules
Both modules enable adjustment in pitch, roll and yaw and allow accurate alignment with machine quill or workpiece.
AM1 adjustment module
The AM1 adjustment module shown below is designed for use on the PH10T PLUS and PH10M PLUS. It has a quick release mechanism
allowing for rapid head exchange and features inbuilt overtravel protection. For further information on the AM1, please refer to the AM1
user's guide (part number H-1000-4010).
PH10 PLUS installation and user's guide
www.renishaw.com
Issued 03 2020
33
