Technical specifications
TP20
Product compatibility The TP20 is suitable for use with all Renishaw probe interfaces and
probe heads which service the TP1, TP2 and TP6 touch-trigger
probes.
The TP20 is compatible with the PEL, PK, PAA and PEM series of
probe extensions / adaptors.
Diameter 13.2 mm
Length - LF / SF / MF / EF 38 mm
Length - EM1 STD 88 mm
Length - EM2 STD 113 mm
Length - 6-way 42 mm
Probe mount Thread M8 x 1.25 x 5 mm
Stylus mount Thread M2 x 0.4
Sense directions - LF / SF / MF / EF / EM1 STD / EM2 STD 5‐way ﴾± X, ± Y, + Z﴿
Sense directions - 6-way 6‐way ﴾± X, ± Y, ± Z﴿
Probe module pull-off force 10 N (1 kgf) maximum
Sealing IP30
Cable length 50 m with (24 awg) conductors
Probe modules life 25,000 changes
MCR20
Length 200 mm
Width 60 mm
Height 145 mm
Port entry velocity Maximum 800 mm/s
Mounting orientation Not designed for horizontal operation with the ports in a vertical
orientation
Y axis overtravel Hinged breakout from base
55 mm travel at port height
Z axis overtravel Hinged docking port assembly
90° travel in –Z axis
Inhibit range 100 mm from port centre
