WPS Status
Displays “Configured” or “unConfigured” depending on whether WPS and
SSID/security settings for the unit have been configured or not, either manually or
using the WPS button.
Self PIN Code
Displays the WPS PIN code of the unit.
Device SSID
Displays the SSID of the unit.
Security Type
Displays the wireless security authentication mode of the device.
Passphrase Key
Displays the wireless security authentication key (or the password of the Wi-Fi
network).
Device Configure
Configuration
Mode
The configuration mode of the unit’s WPS setting is displayed here. “Registrar”
means the unit acts as an access point for a wireless client to connect to and the
wireless client(s) will follow the unit’s wireless settings.
Configure via
Push Button
Click “Start PBC” (Push-Button Configuration) to activate WPS on the unit. WPS
will be active for 2 minutes.
Input Client PIN
Code
Enter the wireless client’s PIN code here and click “Send PIN” to send PIN code to
the WPS-enabled device. Refer to your WPS-enabled device’s documentation if
you are unsure how to obtain its PIN code.
