Renogy 2000W User Manual

22
If User-defined is selected in program 94,this program can
be set up.Setting range is from 13.0V to 15.0V for 12V
Floating charging voltage
If User-defined is selected in program 94,this program can be set
up.Setting range is from 12.0V to 14.0V for 12V
Battery low voltage open
charging(for lithium battery)
V
BATT
V
BATT
V
BATT
b.Once finished, go to Program 27 to set the battery low voltage recovery charge. This will be
the voltage that the battery discharges to before the inverter-charger charges the battery to the
predetermined maximum charging voltage
a.After setting Program 94, go to Program 26 to select the boost charging voltage for your
custom non- lithium battery.
The operation and display
panel,shown in chart below.is on
the front panel of the inverter.It
includes three indicators,four
function keys and an LCD
display,indicating status and
input/output power information.
b.Once finished, go to Program 27 to set the battery float charge.
4.If choosing a custom non-lithium battery (i.e.. Deep cycle), make sure Program 94 is
set to 0tP
Program
Number
Parameter
Setting
Description
27
Program
Number
Parameter
Setting
Description
27
If User-defined is selected in program94,this program can be set
up.Setting range is from 13.0V to 15.0V
Bulk charging voltage(C.V
voltage)
Program
Number
Parameter
Setting
Description
26
Display Panel
LED display
LED indicators
function keys

Renogy 2000W Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Waveform	Pure Sine Wave
Output Frequency	60Hz
THD	<3%
Operating Temperature Range	-4°F to 104°F (-20°C to 40°C)
Protection	Overload, Over Temperature, Short Circuit
Efficiency	90%
USB Port	5V/2.1A
Under Voltage Protection	10V DC
