Renogy 2000W User Manual

07
Dimensions
Included Components
Battery Temperature Sensor (BTS)
Renogy inverter chargers come equipped with a battery temperature sensor that will help
prolong the battery life. The battery sensor allows the inverter charger to continuously
adjust the charging voltage based on the battery temperature. The inverter charger will
compensate charging with a factor of -0.5mV/C◦ per degree after 77F°/25C°, within
-40C°/F° ~ 176F°/80C°. . The sensor should be installed on all battery banks except for
lithium. Simply connect the wire into the terminal block (it is not polarity sensitive), if it is not
connected already. The terminal block may need to be tightened onto the respective BTS
port. Then place the sensor near the battery bank for automatic temperature compensation.
Connect the temperature sensor for all batteries except Lithium for best charging accuracy
NOTE
Note: Dimensions are in millimeter[inches]

Renogy 2000W Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Waveform	Pure Sine Wave
Output Frequency	60Hz
THD	<3%
Operating Temperature Range	-4°F to 104°F (-20°C to 40°C)
Protection	Overload, Over Temperature, Short Circuit
Efficiency	90%
USB Port	5V/2.1A
Under Voltage Protection	10V DC
