Renogy Commander Series - Page 13

12
CAUTION: Do not over-torque or over tighten the screw terminals. This could
potentially break the piece that holds the wire to the charge controller.
CAUTION: Refer to the technical specifications for max wire sizes on the controller
and for the maximum amperage going through wires.
You are now ready to begin connecting your battery to your charge controller.
Battery
1
2
3
4
