30
System Status Troubleshooting
Maintenance
PV indicator Troubleshoot
BATT Indicator Troubleshoot
Load Indicator Troubleshoot
Error Indicator Troubleshoot
Off during daylight
Using a multimeter check the battery voltage and verify it is not
exceeding 32 volts.
Disconnect loads, if any, and let the PV modules charge the battery bank.
Use a multi-meter to frequently check on any change in battery voltage to
see if condition improves. This should ensure a fast charge. Otherwise,
monitor the system and check to see if system improves.
The Load circuit on the controller is being shorted or overloaded. Please
ensure the device is properly connected to the controller and make sure it
does not exceed 20A (DC).
White Slow Flashing
White Fast Flashing
White Fast Flashing
WhiteSolid System Error. Please check LCD for Error code
Ensure that the PV wires are correctly and tightly secured inside the
charge controller PV terminals. Use a multi-meter to make sure the
poles are correctly connected to the charge controller.
1. Check that controller is mounted in a clean, dry, and ventilated area.
2. Check wiring going into the charge controller and make sure there is no wire damage or wear.
3. Tighten all terminals and inspect any loose, broken, or burnt up connections.
4. Make sure LED readings are consistent. Take necessary corrective action.
5. Check to make sure none of the terminals have any corrosion, insulation damage, high
temperature, or any burnt/discoloration marks.
For best controller performance, it is recommended that these tasks be performed from time to time.
Risk of Electric Shock! Make sure that all power is turned off before touching the
terminals on the charge controller.
WARNING
