34
Dimensions in millimeters (mm)
NOTE
Dimensions
RVR60
RVR60 with mounting brackets
Ø4.5
4xØ10
8xØ11.8
205 mm
(8.07 in)
170
102mm
(4.01in)
285mm
(11.22 in)
34mm (1.03in)
102mm
(4.01in)
2.5mm
(0.09in)
227mm
(8.93in)
109.2mm
(4.29in)
285mm
(8.55in)
170mm
(6.69in)
218mm (8.58in)
178mm(7.0in)
180mm
(7.08in)
109.2mm
(4.29in)
2.5mm
(0.09in)
30.5mm (1.02in)

Other manuals for Renogy ROVER Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Renogy ROVER Series and is the answer not in the manual?

Renogy ROVER Series Specifications

General IconGeneral
Temperature Compensation-3mV/°C/2V(Default)
TypeMPPT
Nominal System Voltage12V/24V Auto
Rated Charge Current20A, 30A, 40A, 60A
Max PV Input Voltage100V (20A/30A), 150V (40A/60A)
Max Solar Input Power260W (12V)/520W (24V) for 20A, 390W (12V)/780W (24V) for 30A, 520W (12V)/1040W (24V) for 40A
Battery TypeSealed, Gel, Flooded, Lithium
CommunicationRS232
ProtectionOver Heating
