HYD 3K~6K-EPUser manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 16 -
CAUTION
Please
check the product package and fittings carefully before
installation.
Fig.3-2 HYD 3K~6K-EP inverter overview
Table 3-2 HYD 3K~6K-EP inverter overview
1
Battery input terminals
6
Link Port 1
2
DC switch
7 COM
3
PV input terminals
8
Grid connection port
4 USB/WiFi 9
Load connection port
5
Link Port 0
10 LCD
3.3. Tools
Prepare tools required for installation and electrical connections.
