Operating Instructions
Interface Programming REOVIB MFS 268 - RS 232
10
ELEKTRONIK
4.0 Parameter Table
Non listed addresses should not be changed.
Settings Setting
range
Display-
Code
Factory
settings
Entry
code
Parameter
address
HEX (.bit)
Value range
HEX
Förderer
• Ampltude (throughput)
0..100 % A. 0 % 000,
002,
008, 096
100C 0...FFFF H
• Maximum control range (U
max
)
5..100 % P. 100 % 096, 008
1009 0CCC...FFFF H
• Vibrating frequency (depending on
limits)
5..300 Hz F. 100 Hz 096, 008
1005 01F4..7530 H
500..30000 dec.
(FL.)..(FH.)
• Soft start ramp
0..60 Sec. /. 0,1 Sec. 096 1013 0..FFFF H
• Soft stop ramp
0..60 Sek. \. 0,1 Sek. 096 1012 0..FFFF H
• Connect to external set point
0 / I E.S.P. 0 003 1800.0 0 / 1
• Set point 0(4)...20 mA
0 / I 4.20 0 003 1800.1 0 / 1
• Potentiometer set point
(for 3 / 6 / 8 A units)
0 / I POT. 0 003 1800.5 0 / 1
• Coarse/fine control
0 / I S.P.2. 0 003 1800.12 0 / 1
• Invert enable
0 / I -En. 0 003 1801.1 0 / 1
Regulation (with sensor)
• Switch to regulation mode
0 / I ACC. 0 008 1800.15 0 / 1
• Proportional characteristic
0..100 P.A. 40 008 100F 0..FFFF H
• Integral charcteristic
0..100 I.A. 0 008 1014 0..FFFF H
• Automatic frequency control
0 / I A.F.C. 0 008 1800.9 0 / 1
• Automatic frequency search
start A.F.S. 008
Track control
• Switch-on delay
0..60 Sec. I. 5 Sec. 007, 167
1003 0..FFFF H
• Switch-off delay
0..60 Sec. O. 5 Sec. 007, 167
1002 0..FFFF H
• Invert sensor
PNP / PNP
inverse
-SE. PNP 007, 167
1800.10 0 / 1
Sensor Monitoring
• Activate Sensor Time-out
0 / I E. 0 015 1800.11 0 / 1
• Time (Sensor Time-out)
1..240 Sec.
E.E. Not active 015 1004 0...FFFF H
Serial Interface (only when option is fitted)
• Serial Interface On/Off
0 / I S.I.F. I 017 1801.8 0 / 1
Service
• ERROR Reset
Reset CLr.Er. 009 9004 C009 H
• Hide programming menus
0 / I Hd.C. 117 1800.4 0 / 1
• User parameter menus #. 0...3
0..3 U.S.I. 0 143
• Save user settings
PUSH. 143
• Return to factory settings
FAC. 210
• Select user parameter menu # 0...3
0..3 U.S.I. 0 210
• Return to user settings
US.PA. 210
Service Basic Settings
• Service Menu Enable
0 / I En.S. 0 127 1803.4 0 / 1
• Display current value
i. 040 200A 0..8000 H
• Current limit
0..100 % I. 100 040 1016 0..FFFF H
• Lower frequency limit
5..300 Hz F.L. 35 040 1020 01F4..7530 H
500..30000 dec.
• Upper frequency limit
5..300 Hz F.H. 140 040 1021 01F4..7530 H
500..30000 dec.
