Operating Instructions
Interface Programming REOVIB MFS 268 - RS 232
11
ELEKTRONIK
5.0 Example of serial interface communication with frequency controller REOVIB MFS 268
Variable values are written in italics.
5.1 Normal Operation
(set point set at 70 %)
Send
set point
Word Contents
Send
Contents
Receive
1
B332 H
Set point = 70 %
---
---
2
3
0004 H
Enable ON
A5xx H
Ready
RS 232 Character string
"B33200000004"+CR
RS 232 Character string
"00000000A5xx"+CR
(Control STOP)
Send
Set point
Word Contents
Send
Contents
Receive
1
B332 H
Set point = 70 %
---
---
2
3
0000 H
Enable AUS
A5xx H
Ready
RS 232 Character string
"B33200000000"+CR
RS 232 Character string
"00000000A5xx"+CR
