Page #12 background imageLoading...
Page #12 background image
Operating Instructions
Interface Programming
REOVIB MFS 268 - RS 232
12
ELEKTRONIK
5.2 Parameter Operation
(e.g. Set frequency to 50Hz and soft start to 2 seconds)
Write enable
Word Contents
Send
Contents
Receive
1 C0DE H Address write key C0DE H Confirmation
2 B5E7 H Value write key B5E7 H Confirmation
3 8000 H +
Control bits
Set Mode bit = 1 C0DE H Confirmation
RS 232 Character string
"CODEB5E78000"+CR
RS 232 Character string
"CODEB5E7COD"+CR
Write parameter
1
9005 H
Parameter address
Frequency
+ R / W - Bit
9005 H
Confirmation
2
1388H
Frequency 50 Hz
1388 H
Confirmation 50 Hz
3 8000 H +
Control bits
Set Mode bit = 1 C0DE H Confirmation
RS 232 Character string
"900513888000"+CR
RS 232 Character string
"90051388CODE"+CR
Write parameter
1
9013 H
Parameter address
Soft start
+ R / W - Bit
9013 H
Confirmation
2
3333 H
Soft start 2 s
ecs.
3333 H
Confirmation 2 secs.
3 8000 H +
Control bits
Set Mode bit = 1 C0DE H Confirmation
RS 232 Character string
"901333338002"+CR
RS 232 Character string
"90133333CODE"+CR
Close write
enable
Word Contents
Send
Contents
Receive
1 C0DE H Adresss write key C0DE H Confirmation
2 0000 H Value write key 0000 H Confirmation
3 8000 H +
Control Bits
Set Mode bit = 1 C0DE H Confirmation
RS 232 Character string
"CODE00008000"+CR
RS 232 Character string
"CODE0000CODE"+CR
(Parameter read only)
RS 232 Character string
"101300008000"+CR
RS 232 Character string
"10138000CODE"+CR
Read
Word Contents
Send
Contents
Receive
1
1013 H
Parameter address
Soft start
1013 H
Confirmation
2 0000 H Read Parameter
8000 H
Parameter value ( => 5 Secs)
3 8000 H +
Control bits
Set Mode bit = 1 C0DE H Confirmation Parameter Mode
