Reolink Argus 2 Operational Instruction

• Wall Mount
Step 1
Press the button to release the
plate from the security mount.
Step 3
Latch the security mount on
its plate. (Make sure the top
edge of the backing plate is
inserted into the mount.)
Step 4
Press the security mount
button until its plate clicks into
the mount.
Step 5
Screw the camera, adjust its
direction and tighten the knob
to fix it.
Step 2
Screw the security mount
plate into the wall.
• Tree Mount
Step 4
Latch the security mount on
its plate (make sure the top
edge of the backing plate is
inserted into the mount.)
Step 1
Press the button to release the
plate from the security mount.
Step 5
Press the security mount
button until its plate clicks into
the mount.
Step 6
Screw the camera, adjust its
direction and tighten the knob
to fix it.
Step 2
Thread the hook & loop strap
through the slots.
Step 3
Fasten the warp strap to the
tree.
15English
14 English

Reolink Argus 2 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Form factor	-
Weatherproof	Yes
Mounting type	Desk/Wall
Product color	Black, White
Protection features	Freeze resistant, Heat resistant, Waterproof
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Compatible memory cards	MicroSD (TransFlash)
Night vision distance	10 m
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Battery life	0.5 year(s)
Battery voltage	3.63 V
Battery capacity	5200 mAh
Power source type	Battery
Battery technology	Lithium
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 55 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Mobile operating systems supported	Android, iOS
Number of cameras	1
Detection angle	120 °
Detection distance	9 m
Security algorithms	WEP, WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	59 mm
Width	65 mm
Height	119 mm
Weight	350 g
