Reolink Argus 2 User Manual

Reolink Wireless Battery-powered Camera
9
Argus Eco
Note:
There is no skin and wall mount for Argus Eco, and there is just one mounting
template. Except for the above differences, others are the same as Argus 2.
Argus PT
Note:
Except for the above parts, the surveillance sticker, quick start guide, reset needle
and USB cable are the same as others, but just one pack of screw in this box.
Install a Rechargeable Battery
Argus PT*1
Mounting Template*1
Bracket*1
Strap*1
Slide the battery downward
and lock it firmly.
Check the button status to see
if the battery is installed
correctly.
Argus Eco*1

Reolink Argus 2 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Form factor	-
Weatherproof	Yes
Mounting type	Desk/Wall
Product color	Black, White
Protection features	Freeze resistant, Heat resistant, Waterproof
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Compatible memory cards	MicroSD (TransFlash)
Night vision distance	10 m
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Battery life	0.5 year(s)
Battery voltage	3.63 V
Battery capacity	5200 mAh
Power source type	Battery
Battery technology	Lithium
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 55 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Mobile operating systems supported	Android, iOS
Number of cameras	1
Detection angle	120 °
Detection distance	9 m
Security algorithms	WEP, WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	59 mm
Width	65 mm
Height	119 mm
Weight	350 g
