Reolink Argus 3 User Manual

Reolink Wireless Battery-powered Camera
9
Argus Eco
Note:
There is no skin and wall mount for Argus Eco, and there is just one mounting
template. Except for the above differences, others are the same as Argus 2.
Argus PT
Note:
Except for the above parts, the surveillance sticker, quick start guide, reset needle
and USB cable are the same as others, but just one pack of screw in this box.
Install a Rechargeable Battery
Argus PT*1
Mounting Template*1
Bracket*1
Strap*1
Slide the battery downward
and lock it firmly.
Check the button status to see
if the battery is installed
correctly.
Argus Eco*1

Reolink Argus 3 Specifications

General

Field of View	120°
Audio	Two-Way Audio
Weatherproof	IP65
Wireless Standard	IEEE 802.11b/g/n
Operating Temperature	-10°C to 55°C (14°F to 131°F)
Dimensions	121 x 90 x 56 mm
Resolution	2K (4MP)
Power Source	Rechargeable battery or solar panel
Connectivity	Wi-Fi (2.4GHz)
Image Sensor	CMOS Sensor
Video Resolution	2560 x 1440
Infrared Night Vision	Up to 10 meters (33ft) (IR LED)
Color Night Vision	Yes
PIR Detection Distance	Up to 10 meters
PIR Detection Angle	100°
Wireless Security	WPA-PSK/WPA2-PSK
Battery	5200mAh Rechargeable Battery
Power	Solar panel compatible
Local Storage	microSD card (up to 128GB)
Storage	Micro SD card
Motion Detection	PIR motion detection
Weight	330g
Lens	Fixed Lens, f=2.8mm
