1.6 Ethernet cabling
Run Cat5E Ethernet cable from the location where the PoE is to be
installed to the location of the Trinity-300 unit, allow for some
slack on the wire to avoid putting extra strain on the Ethernet con-
nectors. Make sure the Ethernet cable you are using is rated for
outdoor use to avoid decreased cable life time.
RJ-45 pin-out
If you are not using a pre-assembled Ethernet cable, apply the RJ-
45 connectors on to the both ends of the cable using the pin-out
table and diagram below.
PoE
Wire
Colour
Function
RJ-45
1
Twisted pair
White/Green
Ethernet (RxN)
1
2
Twisted pair
Green
RxT
2
3
Twisted pair
White/Orange
Ethernet (TxT)
3
4
Twisted pair
Orange
Ethernet (TxN)
6
5
Twisted pair
Blue
Power (+)
4
6
Twisted pair
White/Blue
Power (+)
5
7
Twisted pair
White/Brown
Power (-)
7
8
Twisted pair
Brown
Power (-)
8
1.7 Installing the power supply
Install the supplied PoE indoor where power and other network
equipment is available. The PoE can be located at most 100 me-
ters from the unit.
Note The supplied PoE-adapter (Power-over-Ethernet) is strictly
for indoor use only!
