RSSI Ext Chain1 / Chain2
In cases where an additional 20MHz spectrum is used by the link,
the remote RSSI for that spectrum is shown here. So this row will
only be visible when 40MHz spectrum is configured for the link.
Link status
The figure below shows the status information of the radio link.
The parameters are described below.
Figure 15 – Link status.
Link uptime
The time the link has been up since last power up, reconfiguration
or reboot.
Remote MAC
The read MAC address of the remote side of the link.
Current Max Theoretical Throughput Tx/Rx
The max theoretical throughput shows what to expect from the link.
It takes into account the Tx/Rx time division and removes system
overhead.
System status
The figure below shows the system status information. The
parameters are described below.
Figure 16 – System status.
Uptime
The overall system (node) uptime.
Cloud server
Connectivity status of the RCS server (Enabled/Disabled).
RCS
