ATF System with C410:V4B Controller User Guide
109
OPC Inputs (continued)
Tagname plc in DB41
PLC Address
Definition
Units
Data
type
Structure
Tagname in structure
"DB41".
P2_Cal_Enable
%DB41.DBX152.0
Bool
"DB41".
PRV1_Cal_Enable
%DB41.DBX152.1
Bool
"DB41".
PRV2_Cal_Enable
%DB41.DBX152.2
Bool
"DB41".
P3_Cal_Enable
%DB41.DBX152.3
Bool
"DB41".
P4_Cal_Enable
%DB41.DBX152.4
Bool
"DB41".
P5_Cal_Enable
%DB41.DBX152.5
Bool
"DB41".
W1_Cal_Enable
%DB41.DBX152.6
Bool
"DB41".
P2_P1_Capture
%DB41.DBX152.7
Bool
"DB41".
P2_P2_Capture
%DB41.DBX153.0
Bool
"DB41".
P2_Accept
%DB41.DBX153.1
Bool
"DB41".
PRV1_P1_Capture
%DB41.DBX153.2
Bool
"DB41".
PRV1_P2_Capture
%DB41.DBX153.3
Bool
"DB41".
PRV1_Accept
%DB41.DBX153.4
Bool
"DB41".
PRV2_P1_Capture
%DB41.DBX153.5
Bool
"DB41".
PRV2_P2_Capture
%DB41.DBX153.6
Bool
"DB41".
PRV2_Accept
%DB41.DBX153.7
Bool
"DB41".
P3_P1_Capture
%DB41.DBX154.0
Bool
"DB41".
P3_P2_Capture
%DB41.DBX154.1
Bool
"DB41".
P3_Accept
%DB41.DBX154.2
Bool
"DB41".
P4_P1_Capture
%DB41.DBX154.3
Bool
"DB41".
P4_P2_Capture
%DB41.DBX154.4
Bool
"DB41".
P4_Accept
%DB41.DBX154.5
Bool
"DB41".
P5_P1_Capture
%DB41.DBX154.6
Bool
"DB41".
P5_P2_Capture
%DB41.DBX154.7
Bool
"DB41".
P5_Accept
%DB41.DBX155.0
Bool
"DB41".
W1_P1_Capture
%DB41.DBX155.1
Bool
"DB41".
W1_P2_Capture
%DB41.DBX155.2
Bool
"DB41".
W1_Accept
%DB41.DBX155.3
Bool
"DB41".
Force_Solenoid
%DB41.DBX155.4
Bool
"DB41".
PV1_SP
%DB41.DBD156
Real
"DB41".
PV2_SP
%DB41.DBD160
Real
"DB41".
PRV1_SP
%DB41.DBD164
Real
"DB41".
PRV2_SP
%DB41.DBD168
Real
"DB41".
P2_P1_EU
%DB41.DBD172
Calibration - AIW04 - Point 1 - Engineering Value
bar
Real
"DB41".
P2_P2_EU
%DB41.DBD176
Calibration - AIW04 - Point 2 - Engineering Value
bar
Real
"DB41".
PRV1_P1_EU
%DB41.DBD180
Calibration - AIW06 - Point 1 - Engineering Value
bar
Real
"DB41".
PRV1_P2_EU
%DB41.DBD184
Calibration - AIW06 - Point 2 - Engineering Value
bar
Real
"DB41".
PRV2_P1_EU
%DB41.DBD188
Calibration - AIW08 - Point 1 - Engineering Value
bar
Real
"DB41".
PRV2_P2_EU
%DB41.DBD192
Calibration - AIW08 - Point 2 - Engineering Value
bar
Real
"DB41".
P3_P1_EU
%DB41.DBD196
Calibration - AIW12 - Point 1 - Engineering Value
bar
Real
"DB41".
P3_P2_EU
%DB41.DBD200
Calibration - AIW12 - Point 2 - Engineering Value
bar
Real
"DB41".
P4_P1_EU
%DB41.DBD204
Calibration - AIW14 - Point 1 - Engineering Value
bar
Real
"DB41".
P4_P2_EU
%DB41.DBD208
Calibration - AIW14 - Point 2 - Engineering Value
bar
Real
"DB41".
P5_P1_EU
%DB41.DBD212
Calibration - AIW16 - Point 1 - Engineering Value
bar
Real
"DB41".
P5_P2_EU
%DB41.DBD216
Calibration - AIW16 - Point 2 - Engineering Value
Kg
Real
"DB41".
W1_P1_EU
%DB41.DBD220
Calibration - AIW18 - Point 1 - Engineering Value
Kg
Real
