REPLIGEN XCell ATF Series User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
12
Table 4c. XCell™ ATF 6 Pump Housing Parts List
Item
DESCRIPTION
MATERIAL
QTY
1
Pump Hemisphere, Base Plate, Assembly, ATF6
AISI Type 316L
Stainless Steel
1
2
Socket Head Cap Screw, ¼-20 x 3/8 LG
18-8 SS
4
3
Pump Hemisphere, Air Side, ATF 6
SA479 316L SS
1
4
Socket Set Screw, Cup Point, 3/8-16 UNC x ½
LG
18-8 SS
1
5
Diaphragm, Pump, ATF6
50A p.c. Silicone:
BlueStar LSR 4350
1
6
Pump Hemisphere, Liquid side Assembly, ATF6
SA 479 316L SS
1
7
Sanitary Gasket, ½” TC
EPDM
4
8
Sanitary Diaphragm Valve, ½” w/TC ends
316 SS
3
9
Clamp, Sanitary ½”-3/4” TC
304 SS
6
10
Clamp, Sanitary 6.0”TC
AISI 304 SS
1
11
Filter Housing Assembly, ATF6
AISI type 316L stainless steel
1
12
Spectrum F^ 2 Micron PES Hollow Fiber
Cartridge
PC/PS w/Hollow Fibers
1
13
Silicone Size 337 70A O-Ring
Silicone
2
14
Sanitary Gasket, ¾” TC
EPDM
2
15
Pressure Gauge, ¾ TC 30 PSI to -30”Hg
ASI Type 316L stainless steel
1
16
Reducer, ATF6
SA 479 316L SS
1
17
Sanitary Gasket 1” TC
EPDM
1
18
Elbow 90 Deg-1.0, TC Ends
316 SS
1
19
Sanitary Cap ¾”
AISI Type 316L stainless steel
1
20
Sanitary Gasket 1 ½” TC
EPDM
2
21
Clamp Sanitary, 1 ½” TC
304 SS
3
22
Clamp, Sanitary, 3.0” TC, I Line Type
AISI 304 SS
2
23
Window, Sanitary 1/5”TC, With Rem. Glass
Insert
AISI Type 316L stainless steel
2
24
Sanitary Adapter, ¾” Tri-Clamp x ¼” Hose Barb
Fitting
AISI Type 316L Stainless Steel
1
25
Straight Thread/ Swivel Adapter, 3/8” Tube
9/16-18M x 9/16-18F
316 SS
1
26
Male Long Connector, 3/8” Tube OD, 9/16-
18M x ¼” NPTM
316 SS
1
27
45 Deg Female Pipe Elbow, ¼-18NPT x 1/4-NPT
316 SS
1
28
Air Inlet Filter w/1/4” NPT male ends ,& Filter
Vent Caps (2)
PVDF
1
See Appendix 7 for list of spares and accessories
