REPLIGEN XCell ATF Series User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
111
OPC Outputs (continued)
Tagname plc in DB40
PLC Address
Definition
Units
Data
type
Structure
Tagname in structure
"DB40".
DB40_DataLog.DL_APC_VFlowPrimary
%DB40.DBW458
Algorithm Performance Counter 3
Int
"DB40".
DB40_DataLog.DL_APC_VFlowOverride
%DB40.DBW460
Algorithm Performance Counter 4
Int
"DB40".
DB40_DataLog.DL_APC_VFlowOvertime
%DB40.DBW462
Algorithm Performance Counter 5
Int
"DB40".
DB40_DataLog.DL_P2_PV
%DB40.DBD464
P2 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_PRV1_PV
%DB40.DBD468
PRV1 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_PRV2_PV
%DB40.DBD472
PRV2 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_SPARE_PV
%DB40.DBD476
Spare - Process Value
Real
"DB40".
DB40_DataLog.DL_P3_PV
%DB40.DBD480
P3 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_P4_PV
%DB40.DBD484
P4 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_P5_PV
%DB40.DBD488
P5 - Process Value
bar/PSI
Real
"DB40".
DB40_DataLog.DL_W1_PV
%DB40.DBD492
W1 - Process Value
Kg
Real
"DB40".
DB40_DataLog.DL_Bioreactor_Backpressure
%DB40.DBD496
Bioreactor Backpressure
bar/PSI
Real
"DB40".
DB40_DataLog.DL_Model_Num_HMI
%DB40.DBW500
Model Number SP
Int
"DB40".
DB40_DataLog.DL_Height_Differential
%DB40.DBW502
Height Differential SP
CM
Int
"DB40".
DB40_DataLog.DL_Press_Cycle_Delay_Time_SP
%DB40.DBW504
Pressure Cycle Delay Time SP
SEC
Int
"DB40".
DB40_DataLog.DL_Press_Cycle_Over_Time_SP
%DB40.DBW506
Pressure Cycle Over Time SP
SEC
Int
"DB40".
DB40_DataLog.DL_Vac_Cycle_Delay_Time_SP
%DB40.DBW508
Vacuum Cycle Delay Time SP
SEC
Int
"DB40".
DB40_DataLog.DL_BATCH_NO
P#DB40.DBX0.0
Batch Number
String
"DB40".
ATF_HeartBeat
%DB40.DBX512.0
ATF Heartbeat 1 Sec Cycle 50% Duty
Bool
"DB40".
Rem_PB
%DB40.DBX512.1
ATF Remote Profibus Master
Bool
"DB40".
Rem_OPC
%DB40.DBX512.2
ATF Remote OPC Master
Bool
"DB40".
ATF_Trouble
%DB40.DBX512.3
ATF Common Trouble Alarm
Bool
"DB40".
ATF_Running
%DB40.DBX512.4
ATF Status is Running
Bool
"DB40".
ATF_START
%DB40.DBX514.0
AFT Start Command
Bool
"DB40".
ATF_STOP
%DB40.DBX514.1
ATF Stop Command
Bool
"DB40".
ATF_Ack_Alarms
%DB40.DBX514.2
ATF Acknowledge Alarms
Bool
"DB40".
Reset_Counters
%DB40.DBX514.3
Algorithm Performance Counters -
Reset
Bool
"DB40".
ATF_Control_Mode
%DB40.DBX514.4
Control Mode
Bool
"DB40".
ATF_Slope_Enabled
%DB40.DBX514.5
Slope Function Enabled
Bool
"DB40".
DL_ATF_Connected_Bioreactor
%DB40.DBW516
ATF Connected Bioreactor
Int
"DB40".
DL_WATSP
%DB40.DBW518
Warning / Alarm Timer SP
Min
Int
"DB40".
DL_Pres_Cycl_PV_Step_Size
%DB40.DBD520
Pressure Cycle - PV Step Size - %
Stroke %
Real
"DB40".
DL_Exhs_Cycl_PV_Step_Size
%DB40.DBD524
Exhaust Cycle - PV Step Size
bar/PSI
Real
"DB40".
DL_P2_Pressure_Alarm_Hi_Hi_SP
%DB40.DBD528
P2 - Alarm SP - High High
bar/PSI
Real
"DB40".
DL_P2_Alarm_Hi_Hi_TMR_SP
%DB40.DBW532
P2 - Alarm Delay SP - High High
SEC
Int
"DB40".
DL_P2_Pressure_Alarm_Lo_Lo_SP
%DB40.DBD534
P2 - Alarm SP - Low Low
bar/PSI
Real
"DB40".
DL_P2_Alarm_Lo_Lo_TMR_SP
%DB40.DBW538
P2 - Alarm Delay SP - Low Low
SEC
Int
