ActiveDataPage and ATF_Heartbeat are provided on every output page, so the Master can
continually monitor the communication integrity and verify the data page being provided.
Profibus Configuration for DCS Integration
The XCell™ ATFC410v4 controller is configured as a slave Profibus node; at node address 2
(default). The Siemens CM-1242-5 Profibus DP slave module’s baud-rate is detected
automatically when connected to the DP network. It is configured not to exceed 1.5 Mbps and
is tested at 187.5 kbps.
Profibus address can be changed from the HMI Admin screen (For HMI-enabled units only,
black-box configured controller Profibus address is set at the factory). ProfiBus1 & Profibus2
options on the HMI display Profibus values in the PLC which can be accessed remotely. See
Section 6.3 (F2) for details.
Black-Box Configuration
Black-box configuration is similar to remote control mode but allows completely remote
operation of the XCell™ ATF system with HMI disabled at the factory. Black-box configuration
can be requested at time of ordering a new system.
Prerequisites
The XCell™ ATF should be calibrated and connected to a Bioreactor or other vessel.
The XCell™ ATF should be in a Remote Control Mode.
Remote Set-up
The master sends input parameters pages 1 and 2 to XCell™ ATF or set up the parameters
locally. The Start/Stop parameter should be “0”.
Remote Start
The master sends analog input parameters page 0 to XCell™ ATF. Initially, the Start/Stop bit
should be reset to “0”.
The master starts the filtration by setting the Start/Stop bit to “1”. It is recommended that
unless operator intervention is required, “SendingDataPage” should remain at 0.
Remote Stop
The master stops the filtration by resetting the Start/Stop bit to “0”. The ATF stops running. It
is recommended that unless operator intervention is required, “SendingDataPage” should
remain at 0.
Remote running
During a run it is possible to change all parameters remotely.
If the XCell™ ATF is changed from Remote Control Mode to Local Control Mode, it continues to
run, and it is possible to stop the run from the HMI. If the filtration has been stopped locally
and then changed back to Remote Control Mode it will not restart. To restart the filtration the
master has to reset the Start/stop bit to 0 and then back to 1.
