40
Weight TREND
Available in the TRENDING screen
During the XCell™ ATF System cycle, the weight of the Filtration Assembly changes in response
to the liquid flow to and from Diaphragm Pump. The weight profile is directly proportional to
the position of the diaphragm within the Diaphragm Pump which drives how much liquid is in
the Diaphragm Pump. This provides useful real time information on the position of the
diaphragm within the Diaphragm Pump, which is indicative of the cycle time and the
effectiveness of the pressure and vacuum cycles.
That information may be used to:
i. Monitor if the diaphragm cycles its full stroke.
ii. Display the position of the diaphragm in the Diaphragm Pump.
