ATF System with C410:V4B Controller User Guide
42
Two (2) Pump Controller Status Relays are provided which energize per the following states:
XCell™ ATF System
States
State #
RELAY #1
RELAY #2
POWER OFF / ALARM
A
OFF
OFF
POWER ON /
STANDBY
B
OFF
ON
POWER ON /
RUNNING
C
ON
ON
POWER ON /
WARNING
D
ON
OFF
Two (2) Pump Interlock Relays are provided which energize per the following states:
HARVEST PUMP STATE
RELAY #3
RELAY #4
ACTIVE
ON
ON
NOT ACTIVE
OFF
OFF
An isolated Form C contact for each relay is provided for the end user to connect to any
remote monitoring system. The Harvest pump is activated to Run mode, only and only if
Relay #1 is ON, i.e. in Power On/ Running state #C or Power On / Warning state #D.
The following is a list of C410v4B controller Warnings that can occur during normal operation:
• Flow Set Point cannot be reached. P-Flow Regulator (PV1) above maximum operating
setting.
• Flow Set Point cannot be reached. P-Flow Regulator (PV1) below minimum operating
setting.
• Exhaust Set Point cannot be reached. E-Flow Regulator (PV2) above maximum operating
setting.
• Exhaust Set Point cannot be reached. E-Regulator (PV2) below minimum operating
setting.
• P2 Pressure below Lo Lo Limit.
The following is a list of C410v4B controller Alarms that can occur during normal operation:
• XCell™ ATF System Warning has not been acknowledged. XCell™ ATF System function
halted.
• Main Power Loss (120/220) while Diaphragm Pump was running.
• P2 Pressure Above HI HI Limit
