Profibus Output Signals (from XCell™ ATF to Master)
The following parameters can be read by the Profibus Master. The XCell™ ATF controller sends
parameters with the system in remote or local control mode. The heartbeat signal toggles every 1000ms.
Output Page 0
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
OutputPageX
ActiveDataPage
%DB31.DBW310
Active Data Page
Int-16
1
2
0
OutputPageX
ATF_HeartBeat
%DB31.DBX312.0
ATF Heartbeat
Byte
1
OutputPageX
Rem_Profibus
%DB31.DBX312.1
ATF Remote Mode (Profibus)
2
OutputPageX
ATF_Trouble
%DB31.DBX312.2
ATF Common Trouble Alarm
3
OutputPageX
ATF_Running
%DB31.DBX312.3
ATF Run Status
4
OutputPageX
Pump_Alarm_0
%DB31.DBX312.4
Pump Alarm
5
OutputPageX
Pump_Alarm_1
%DB31.DBX312.5
Power Loss While Pump Running Alarm
6
OutputPageX
Pump_Alarm_2
%DB31.DBX312.6
P2 High High Pressure Alarm
7
3
OutputPage0
PFLOW
%DB31.DBD314
ATF Pressure Cycle Flow
LPM
Real
4
5
6
7
OutputPage0
PTIME
%DB31.DBD318
ATF Pressure Cycle Time
SEC
Real
8
9
10
11
OutputPage0
EFLOW
%DB31.DBD322
ATF Exhaust Cycle Flow
LPM
Real
12
13
14
15
OutputPage0
ETIME
%DB31.DBD326
ATF Exhaust Cycle Time
SEC
Real
16
17
18
19
OutputPage0
PV1
%DB31.DBD330
ATF Pressure Proportional Valve (PV1) Position
%
Real
20
21
22
23
OutputPage0
PV2
%DB31.DBD334
ATF Exhaust Proportional Valve (PV2) Position
%
Real
24
25
26
27
OutputPage0
PRV1_PV
%DB31.DBD338
ATF Pressure at PRV1
BAR/PSI
Real
28
29
30
31
OutputPage0
PRV2_PV
%DB31.DBD342
ATF Pressure at PRV2
BAR/PSI
Real
32
33
34
35
OutputPage0
P2_PV
%DB31.DBD346
ATF Pressure at P2
BAR/PSI
Real
36
37
38
39
OutputPage0
APC_PFlowPrimary
%DB31.DBW350
Algorithm Perfomance Counter - P-Flow - Primary
Int-16
40
41
OutputPage0
APC_PFlowOverride
%DB31.DBW352
Algorithm Perfomance Counter - P-Flow - Override
Int-16
42
43
OutputPage0
APC_PFlowOvertime
%DB31.DBW354
Algorithm Perfomance Counter - P-Flow - Overtime
Int-16
44
45
OutputPage0
APC_VFlowPrimary
%DB31.DBW356
Algorithm Perfomance Counter - V-Flow - Primary
Int-16
46
47
OutputPage0
APC_VFlowOverride
%DB31.DBW358
Algorithm Perfomance Counter - V-Flow - Override
Int-16
48
49
OutputPage0
APC_VFlowOvertime
%DB31.DBW360
Algorithm Perfomance Counter - V-Flow - Overtime
Int-16
50
51
OutputPage0
P3_PV
%DB31.DBD362
ATF Pressure at P3
BAR/PSI
Real
52
53
54
