REPLIGEN XCell ATF10 User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
88
Output Page 0 (continued)
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
55
0
OutputPage0
Warning_0
%DB31.DBX366.0
PV1>=PV1Max
Byte
1
OutputPage0
Warning_1
%DB31.DBX366.1
PV1<=PV1Min
2
OutputPage0
Warning_2
%DB31.DBX366.2
PV2>=PV2Max
3
OutputPage0
Warning_3
%DB31.DBX366.3
PV2<=PV2Min
4
OutputPage0
Warning_4
%DB31.DBX366.4
P2<=P2 Low Low Setpoint
5
OutputPage0
System Stop Active
%DB31.DBX366.5
Set when SS pressed, reset when ATF start or first scan
6
OutputPage0
%DB31.DBX366.6
7
OutputPage0
%DB31.DBX366.7
56
0
OutputPage0
PB_ATF_START_STOP
%DB31.DBX367.0
AFT Start/Stop
Byte
1
OutputPage0
PB_ATF_Ack_Alarms
%DB31.DBX367.1
ATF Acknowledge Alarms
2
OutputPage0
PB_Reset_Counters
%DB31.DBX367.2
Algorithm Performance Counters - Reset
3
OutputPage0
PB_ATF_Control_Mode
%DB31.DBX367.3
Control Mode
4
OutputPage0
PB_ATF_Slope_Enabled
%DB31.DBX367.4
Slope Function Enabled
5
%DB31.DBX367.5
6
%DB31.DBX367.6
7
%DB31.DBX367.7
57
OutputPage0
ATF_Connected_Bioreactor
%DB31.DBW368
ATF Connected Bioreactor
Int-16
58
59
OutputPage0
BatchName[0]
%DB31.DBB370
Batch Name
ASCII
60
BatchName[1]
%DB31.DBB371
ASCII
61
BatchName[2]
%DB31.DBB372
ASCII
62
BatchName[3]
%DB31.DBB373
ASCII
63
BatchName[4]
%DB31.DBB374
ASCII
