REPLIGEN XCell ATF10 User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
91
Output Page 2
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
OutputPageX
ActiveDataPage
%DB31.DBW310
Active Data Page
Int-16
1
2
0
OutputPageX
ATF_HeartBeat
%DB31.DBX312.0
ATF Heartbeat
Byte
1
OutputPageX
Rem_Profibus
%DB31.DBX312.1
ATF Remote Mode (Profibus)
2
OutputPageX
ATF_Trouble
%DB31.DBX312.2
ATF Common Trouble Alarm
3
OutputPageX
ATF_Running
%DB31.DBX312.3
ATF Run Status
4
OutputPageX
Pump_Alarm_0
%DB31.DBX312.4
Pump Alarm
5
OutputPageX
Pump_Alarm_1
%DB31.DBX312.5
Power Loss While Pump Running Alarm
6
OutputPageX
Pump_Alarm_2
%DB31.DBX312.6
P2 High High Pressure Alarm
7
3
OutputPage2
PV2
%DB31.DBD542
Exhaust Proportional Valve Setpoint
%
Real
4
5
6
7
OutputPage2
Model_Num_HMI
%DB31.DBW546
ATF Model Number
Int-16
8
0=ATF4, 1=ATF4MC, 2=ATF6, 3=ATF10lgcy & 4=ATF10
9
OutputPage2
WATSP
%DB31.DBW548
Warning / Alarm Timer SP
MIN
Int-16
10
11
OutputPage2
Bioreactor_Backpressure
%DB31.DBD550
Bioreactor Pressure
BAR/PSI
Real
12
13
14
15
OutputPage2
Height_Differential
%DB31.DBW554
Height Differential
CM
Int-16
16
17
OutputPage2
FDFOFST
%DB31.DBD556
Flow Driving Force Offset for Switching
BAR/PSI
Real
18
19
20
21
OutputPage2
Press_Cycle_Delay_Time_SP
%DB31.DBW560
Pressure Cycle Delay Time SP
%
Int-16
22
23
OutputPage2
Press_Cycle_Over_Time_SP
%DB31.DBW562
Pressure Cycle Over Time SP
%
Int-16
24
25
OutputPage2
Pres_Cycl_PV_Step_Size
%DB31.DBD564
Pressure Cycle - PV Step Size - %
%
Real
26
27
28
29
OutputPage2
EDFOFST
%DB31.DBD568
Exhaust Driving Force Offset for switching
BAR/PSI
Real
30
31
32
33
OutputPage2
Vac_Cycle_Delay_Time_SP
%DB31.DBW572
Vaccum Cycle Delay Time SP
%
Int-16
34
35
OutputPage2
Vac_Cycle_Over_Time_SP
%DB31.DBW574
Vaccum Cycle Over Time SP
%
Int-16
36
37
OutputPage2
Exhs_Cycl_PV_Step_Size
%DB31.DBD576
Exhaust Cycle - PV Step Size
%
Real
38
39
40
41
OutputPage2
P2_Pressure_Alarm_Hi_Hi_SP
%DB31.DBD580
P2 - Alarm SP - High High
BAR/PSI
Real
42
43
44
45
OutputPage2
P2_Alarm_Hi_Hi_TMR_SP
%DB31.DBW584
P2 - Alarm Delay SP - High High
10MSEC
Int-16
46
47
OutputPage2
P2_Pressure_Alarm_Lo_Lo_SP
%DB31.DBD586
P2 - Alarm SP - Low Low
BAR/PSI
Real
48
49
50
51
OutputPage2
P2_Alarm_Lo_Lo_TMR_SP
%DB31.DBW590
P2 - Alarm Delay SP - Low Low
10MSEC
Int-16
52
53
OutputPage2
PFLOWMAXSP
%DB31.DBD592
Max Pressure Flow Setpoint
LPM
Real
54
55
56
57
OutputPage2
PFLOWMINSP
%DB31.DBD596
Min Pressure Flow Setpoint
LPM
Real
58
59
60
61
OutputPage2
LastSentInputPage
%DB31.DBW600
Last Sending Data Page Number
Int-16
62
63
%DB31.DBX602
Output Page 3
